4A Series Air Control Valve

  • Sliding Column Structure for Sensitive Reaction
  • Integrated Memory Function in Double Air Control Models
  • Specialized Low-Friction Internal Orifice Processing
  • Low Starting Pressure & Extended Service Life
  • Oil-Free and Maintenance-Free Operation
  • Manifold-Ready for Space-Saving Installation
  • Naturally Explosion-Proof (No Electrical Spark Risk)
  • Versatile 5/3 Way Centering Options: Closed, Exhaust, and Pressure Center
  • High-Frequency Switching Performance
  • Precision Machined Aluminum Alloy Body
  • Wide Port Size Range from M5 to 1/2"
  • Compact Design for High-Density Pneumatic Systems

4A series is the industry benchmark for air-piloted directional control. Designed for high-frequency switching and long-term durability, these valves operate using external air pilot signals rather than electrical solenoids. This makes them the perfect choice for explosion-proof environments, high-temperature areas, or systems where purely pneumatic logic is required.


From the compact 100 series for space-saving applications to the high-flow 400 series for heavy-duty actuators, the 4A family offers a versatile range of configurations, including 5/2 way single/double control and 5/3 way centering functions.


Available Models in this Collection:

  • M5 Port Series (Compact Design):

    • 4A110-M5: 5/2 Way Single Air Control

    • 4A120-M5: 5/2 Way Double Air Control

    • 4A130C-M5: 5/3 Way Double Air Control (Closed Center)

    • 4A130E-M5: 5/3 Way Double Air Control (Exhaust Center)

    • 4A130P-M5: 5/3 Way Double Air Control (Pressure Center)

  • 1/8" Port Series (Standard Flow):

    • 4A110-06: 5/2 Way Single Air Control

    • 4A120-06: 5/2 Way Double Air Control

    • 4A130C-06: 5/3 Way Double Air Control (Closed Center)

    • 4A130E-06: 5/3 Way Double Air Control (Exhaust Center)

    • 4A130P-06: 5/3 Way Double Air Control (Pressure Center)



Featured Models in the 4A200 Collection:

  • 1/8" Port Series (Standard Flow - 06):

    • 4A210-06: 5/2 Way Single Air Control

    • 4A220-06: 5/2 Way Double Air Control

    • 4A230C-06: 5/3 Way Double Air Control (Closed Center)

    • 4A230E-06: 5/3 Way Double Air Control (Exhaust Center)

    • 4A230P-06: 5/3 Way Double Air Control (Pressure Center)

  • 1/4" Port Series (High Flow - 08):

    • 4A210-08: 5/2 Way Single Air Control

    • 4A220-08: 5/2 Way Double Air Control

    • 4A230C-08: 5/3 Way Double Air Control (Closed Center)

    • 4A230E-08: 5/3 Way Double Air Control (Exhaust Center)

    • 4A230P-08: 5/3 Way Double Air Control (Pressure Center)


Comprehensive Range of 4A300 Models:

  • 1/4" Port Series (Standard High Flow - 08):

    • 4A310-08: 5/2 Way Single Air Control

    • 4A320-08: 5/2 Way Double Air Control

    • 4A330C-08: 5/3 Way Double Air Control (Closed Center)

    • 4A330E-08: 5/3 Way Double Air Control (Exhaust Center)

    • 4A330P-08: 5/3 Way Double Air Control (Pressure Center)

  • 3/8" Port Series (Extra Large Flow - 10):

    • 4A310-10: 5/2 Way Single Air Control

    • 4A320-10: 5/2 Way Double Air Control

    • 4A330C-10: 5/3 Way Double Air Control (Closed Center)

    • 4A330E-10: 5/3 Way Double Air Control (Exhaust Center)

    • 4A330P-10: 5/3 Way Double Air Control (Pressure Center)


Available Models in the 4A400 Series (1/2" Port):

  • 5/2 Way Air Control Valves:

    • 4A410-15: 5/2 Way Single Air Control (Spring Return)

    • 4A420-15: 5/2 Way Double Air Control (Memory Function)

  • 5/3 Way Air Control Valves (Three Centering Functions):

    • 4A430C-15: 5/3 Way Double Air Control (Closed Center)

    • 4A430E-15: 5/3 Way Double Air Control (Exhaust Center)

    • 4A430P-15: 5/3 Way Double Air Control (Pressure Center)
