CM3 Series Short Type Pneumatic Cylinder CM3 Series Short Type Pneumatic Cylinder CM3 Series Short Type Pneumatic Cylinder

CM3 Series Short Type Pneumatic Cylinder

  • CM3 cylinder
  • short type pneumatic cylinder
  • compact air cylinder
  • lightweight automation cylinder
  • bore 20-40mm cylinder
  • double acting short cylinder
  • CDM3 auto switch cylinder
  • male female thread cylinder
  • multi-mount pneumatic cylinder
  • space-saving round cylinder
  • RoHS compliant cylinder
The CM3 Series is a high-performance short-type pneumatic cylinder designed for space-saving automation with a revolutionary compact construction. Engineered to maximize installation efficiency, this cylinder offers significant length reduction (up to 66mm) and weight reduction (up to 21%) compared to conventional round-body cylinders, making it ideal for downsizing modern equipment.

Featuring a robust, impact-resistant barrel that prevents deformation from external shocks, the CM3 ensures durable performance in industrial environments. The series comes standard with selectable male or female rod-end threads, expanding application flexibility and simplifying integration.


Key Specifications:

  • Bore Sizes: 20, 25, 32, 40 mm

  • Action: Double acting, single rod (CM3 / CDM3)

  • Strokes: 25 mm to 300 mm

  • Auto Switch Compatible: CDM3 variant with built-in magnet for D-M9/D-A90 series switches

  • Mounting Variety: Basic, foot, flange, clevis, trunnion, and single clevis mounts

  • Max. Swivel Angle: Up to 202° (CM3C40)



  • The CM3’s compact design and versatile mounting support precise linear motion in automated machinery, small conveying systems, packaging equipment, and compact assembly lines.
