CQ2 Series Compact Pneumatic Cylinder CQ2 Series Compact Pneumatic Cylinder CQ2 Series Compact Pneumatic Cylinder CQ2 Series Compact Pneumatic Cylinder

CQ2 Series Compact Pneumatic Cylinder

  • SMC CQ2 cylinder
  • SMC CDQ2B cylinder
  • CQ2B compact cylinder
  • SMC short stroke cylinder
  • double acting compact air cylinder
  • SMC automation actuator
  • low profile pneumatic cylinder
  • CQ2 series
  • CDQ2B air cylinder
The SMC Type CQ2 Series (including CQ2B, CDQ2B, CQ2KW, etc.) is a line of space‑saving compact pneumatic cylinders designed for high‑density automation systems. Characterized by its short, low‑profile body, the CQ2 series delivers powerful output force in a minimal installation space, making it the go‑to choice for applications with tight spatial constraints.
Built to SMC’s high precision standards, the CQ2 series features a double‑acting design with optional single‑acting variants. The standard CQ2B model comes with a rubber bumper, while the CDQ2B variant is equipped with an air cushion for smoother end‑of‑stroke operation and reduced noise. Its compact structure does not compromise on rigidity, ensuring stable linear motion even under moderate lateral loads.


  • Ultra‑compact design: Short body length saves installation space, ideal for compact machinery

  • Double acting as standard; single‑acting options available (CQ2 series)

  • Air cushion / rubber bumper: CDQ2B models offer adjustable air cushion; CQ2B uses fixed bumper

  • Bore sizes: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm

  • High rigidity: Compact structure with stable thrust and low friction

  • Auto‑switch ready: Built‑in magnet for SMC D‑M9 series magnetic switches

  • Multiple mounting options: Square flange, foot, pin, and bracket mounts for flexible integration

  • Maintenance‑free: Non‑lubricated operation compatible with standard industrial air

Technical Specifications

  • Operating Pressure: 0.1 – 0.7 MPa

  • Temperature Range: -10°C to +60°C

  • Speed Range: 50 – 500 mm/s

  • Port Thread: M5×0.8 (small bores), Rc 1/8", Rc 1/4" (large bores)

  • Standard Stroke: 5 – 100 mm (varies by bore size)

  • Non‑rotation accuracy: ±0.1° (optional anti‑rotation versions)


Applications

  • Small assembly systems & precision clamping

  • Medical device manufacturing & lab automation

  • Electronics & semiconductor handling

  • Packaging machinery & fixture positioning

  • Automated sorting & pushing systems

  • General industrial automation with space limitations
