SDA Series Compact Thin Pneumatic Cylinder
- SDA cylinder
- SDA series compact cylinder
- thin pneumatic cylinder
- slim air cylinder
- double acting compact cylinder
- space-saving air cylinder
- magnetic switch compatible thin cylinder
- AirTAC automation compact actuator
The AirTAC Type SDA Series is a high-performance compact thin pneumatic cylinder designed for space-limited automation equipment. Featuring an ultra-slim, short-length body structure, it provides stable thrust and reliable linear motion while greatly reducing installation space.
Built with high-strength aluminum alloy and precision wear-resistant seals, the SDA series ensures smooth operation, low friction, and long service life. The standard built-in magnetic ring allows direct installation of AirTAC magnetic switches for position detection. With multiple mounting surfaces and flexible connection options, it is widely used in various compact automated machinery.
Ultra-thin and compact body design for space-saving installation
Double-acting, single rod structure with stable thrust output
High-strength aluminum alloy barrel with hard anodizing treatment
High-quality sealing system for low friction and long service life
Built-in magnet for magnetic switch position sensing
Fixed rubber bumper cushion to reduce impact and noise
Multiple mounting holes for flexible installation
Wide pressure and temperature range for versatile industrial use
Technical Specifications
Bore sizes: 12, 16, 20, 25, 32, 40, 50, 63, 80, 100 mm
Operating pressure: 0.1 – 0.7 MPa
Temperature range: -20°C ~ +70°C
Speed range: 50 – 500 mm/s
Port thread: M5×0.8, PT 1/8", PT 1/4"
Standard strokes: 5 to 100 mm
Applications
Widely used in automated machinery, electronic assembly, fixture clamping, pushing, ejecting, packaging equipment, small conveying systems, and other space-limited automation applications.
