TN / TDA Series Double Rod Cylinder
- TN cylinder
- TDA cylinder
- double rod cylinder
- twin shaft cylinder
- AirTAC TN TDA
- dual rod pneumatic cylinder
- anti-rotation air cylinder
- compact double shaft cylinder
- automation twin rod cylinder
The AirTAC Type TN and TDA Series are high-performance double rod pneumatic cylinders designed for stable linear motion in compact automation equipment. Featuring a dual piston rod structure, these twin-shaft cylinders provide excellent anti-rotation, anti-bending and high lateral load capacity, ensuring accurate positioning and smooth operation.
TN and TDA series share the same performance characteristics with interchangeable dimensions, widely recognized as reliable and cost-effective twin shaft cylinders in the automation industry.
Double rod / twin shaft design for superior anti-rotation and high rigidity
Double acting for stable bidirectional thrust
Built-in magnet for magnetic switch position detection
Compact and lightweight structure, easy to install
High-quality sealing system for low friction and long service life
Wide operating pressure and temperature range
Fixed rubber bumper cushion to reduce impact and noise
Technical Specifications
Bore sizes: 10, 16, 20, 25, 32, 40 mm
Operating pressure: 0.1–0.7 MPa
Temperature range: -20°C ~ +70°C
Port thread: M5×0.8.1/8.1/4.1/2
Applications
Widely used in automation machinery, electronic assembly, packaging, fixture clamping, pushing, ejecting, conveying and precision positioning systems.
