The SMC MXJ Series is an ultra-compact, high-precision miniature air slide table engineered for micro and compact automation systems. Featuring an integrated high-rigidity linear guide and martensitic stainless-steel construction, this slide cylinder delivers exceptional positioning accuracy and smooth linear motion in an incredibly small footprint.
Key Features (SMC Official Specs):

  • Ultra-Compact & Lightweight: Slim profile (e.g., MXJ4: H10mm × W20mm), minimal weight for space-constrained installations.

  • High Precision Linear Guide: Achieves travel parallelism of 0.005mm and mounting parallelism of 0.03mm for ultra-fine positioning.

  • Bore Sizes: 4.5, 6, 8, 12, 16 mm.

  • Standard Strokes: 5, 10, 15, 20, 30, 50 mm.

  • Double Acting: Standard double-acting operation for precise push/pull control.

  • Integrated Rigid Structure: One-piece body and table design for high rigidity and stable load performance.

  • Multi-Face Mounting: Versatile installation from top, side, and bottom; 4-sided mounting pin holes.

  • Flexible Options:

    • Symmetric port/switch groove design for side-by-side mounting.

    • Stroke adjusters (metal limiters: CS/CT/C).

    • Axial piping & auto-switch compatible (D-M9 series).

    • Standard & clean room specifications available.

  • Durable Materials: Martensitic stainless steel guides and body for corrosion resistance.

  • RoHS Compliant: Meets global environmental standards.

Applications:
Perfect for micro-positioning, clamping, transferring, sorting, and assembly in electronics, semiconductor, medical devices, and small-scale automation where ultra-compact size, high precision, and zero-play movement are critical.
