TWQ & TTQ Series Lever Stopper Cylinder
- Heavy-duty lever-type stopper cylinder
- High impact resistance for high-inertia loads
- Integrated shock absorber for smooth, bounce-free stopping
- Durable aluminum alloy body with hard-anodized finish
- Compact design for low-profile conveyor systems
- Magnetic auto-switch compatible (flush T-slots)
- Bore sizes: 20mm, 25mm, 32mm, 40mm, 50mm
- Ideal for pallet conveyors and automated sorting lines
- High-frequency response and long service life
- Reliable operation in various industrial environments.
TWQ & TTQ Series: Precision Lever-Type Stopper Cylinders
The TWQ and TTQ series are specialized heavy-duty pneumatic actuators designed for the most demanding conveyor applications. Unlike standard vertical stoppers, these lever-type cylinders use a mechanical advantage and integrated cushioning to halt pallets smoothly, even when carrying high-inertia loads. They are the essential choice for high-speed automated production and sorting lines.
Key Technical Features & Engineering Highlights
High-Efficiency Shock Absorption: Equipped with an integrated, high-performance shock absorber (often adjustable) that ensures workpieces stop without a rebound, protecting delicate components and reducing noise.
Robust Lever Mechanism: The heavy-duty lever design is engineered to withstand massive frontal impact forces. The pivot points are reinforced to ensure long-term reliability under high-frequency operation.
Self-Locking Safety: The internal geometry provides a stable stop position, ensuring that even if air pressure fluctuates, the pallet remains securely held in place.
Space-Saving Profile: Designed with a compact aluminum alloy body, these cylinders are easy to install in low-profile conveyor frames where vertical space is limited.
Sensor-Ready Design: Features integrated slots for the flush mounting of magnetic auto-switches (sensors) for precise position feedback to the PLC.
Technical Specifications Overview
Primary Industrial Applications
The TWQ/TTQ series is the preferred actuator for:
Automated Logistics: Managing pallet flow in high-speed distribution centers.
Electronics Assembly: Gentle stopping for delicate SMT tray carriers.
Packaging Lines: Precise spacing and stopping for boxing and labeling machines.
Automotive Parts Handling: Controlling the movement of engine and transmission sub-assemblies.
